AIWAFT
AIWaft 4K PTZ Pro Lens Camera – 12X Zoom, Best for Online Teaching, Live Streaming & Classroom Recording, HDMI/SDI/USB/IP
Key Features
- 4K Ultra HD Resolution: Delivers crisp and clear visuals.
- 12X Optical Zoom: Smooth zooming
- Auto Focus & Low-Light Performance: Ensures high-quality video.
- Multiple Connectivity: HDMI, SDI, USB3.0, USB2.0, and IP (RTSP, RTMP).
- POE Support: Easy single-cable installation.
- Wide Compatibility: Works with Zoom, Google Meet, OBS, and more.
- Smooth Pan, Tilt & Zoom: 170° pan & 90° tilt for flexible coverage.
- Ideal for Online Teaching & Live Streaming: Perfect for classrooms, webinars, and events.
Technical Details
| Brand | AIWaft |
|---|---|
| Manufacturer | AIWaft Private Limited |
| Modal Number | AIW20A2 |
| Video Format | HDMI: 1920*1080P60/50/30/25/59.94/29.97/24/23.98, 1920*1080i60/50/59.94, 1280*720P60/50/30/25/59.94/29.97 |
| SDI: 1920*1080P60/50/30/25/59.94/29.97/24/23.98 , 1920*1080160/50/59.94, 1280*720P60/50/30/25/59.94/29.97 | |
| USB: 1920*1080P60/50/30/25(USB3.0), 1280*720P60/50/30(USB3.0), 1280*720P25(USB3.0&USB2.0), 1024*576P30(USB3.0&USB2.0), 960*540P30(USB2.0), 640*360P30(USB2.0), 512*288P30(USB2.0) | |
| IP Main Stream: 1920*1080@3~30; 1280*720@3~30; 1024*576@3~30, Sub Stream: 1280*720@3~30; 1024*576@3~30; 640*360@3~30 | |
| Video Interface | HDMI, SDI, RJ45, USB3.0, USB2.0 |
| Sensor | 1/2.8" 2.4MP CMOS sensor |
| View Angle | 72.5°(Far)-6.43° (Near) |
| Zoom | F3.92~47.32mm(12X) |
| Rotation Angle | Pan: -170°~+170°, Tilt: -30°~+90° |
| Rotation Speed | Pan: 0°~120°/s, Tilt: 0°~80°/s |
| Preset | Remote controller: 10; RS232: 128; Accuracy: 0.1° |
| Control Port | RS232, RS485(optional), RJ45 (VISCA over IP), USB3.0 (UVC1.5), USB2.0 (UVC1.1) |
| Network Speed | 1000M |
| Video encode | H.264/H.265(default: H.264) |
| Bit Rate Control | Variable Bit Rate, Constant Bit Rate |
| Video Bit Rate | 0Kbps~15360Kbps |
| IP Protocol | TCP/IP, HTTP, RTSP, DHCP, RTMP, Onvif, VISCA over IP(TCP&UDP), HTMLS, VISCA, PELCO-P/D |
| POE | Supported |
| Daisy Chain | Support RS232 serial daisy chain |
| Minimum Lux | 0.01lux |
| White Balance | ATW/Manual/Auto/Indoor/Outdoor/Push |
| Exposure | Auto/Manual/Shutter/Iris/Bright |
| Focus | Auto/Manual |
| Iris | Auto/Manual |
| Electric Shutter | Auto/Manual |
| Gamma | Supported |
| WDR | Supported |
| BLC | Supported |
| 2D Noise Reduction | Supported |
| 3D Noise Reduction | Supported |
| Anti Flicker | OFF/50Hz/60Hz |
| Pan Tilt Flip | Supported |
| Input Voltage | DC12V/POE(IEEE802.3af) |
| Dimension | 220mm×190mm×173mm |
| Net Weight | 1.40kg |
Capture Every Detail with Precision
The AIWaft 4K PTZ Pro Lens Camera redefines clarity, offering ultra-smooth pan, tilt, and zoom capabilities for a superior video experience in online teaching, webinars, and professional recordings.
Experience superior image quality with advanced 2D and 3D noise reduction technology. It effectively minimizes grainy distortions, ensuring crystal-clear visuals even in low-light environments. Perfect for professional video calls, recordings, and live streaming.
Easily manage your camera’s movements and settings remotely for smooth and hassle-free presentations, meetings, or live sessions. Enjoy precise control over pan, tilt, and zoom functions, enhancing your overall video experience.
Save valuable time by configuring up to 255 custom presets, allowing instant transitions between different camera angles and settings. Ideal for dynamic presentations, online teaching, and professional broadcasts.
Achieve sharp, high-quality visuals with the flexibility to switch between auto and manual focus modes. Auto mode ensures real-time clarity, while manual mode provides full control for capturing precise details in any setting.
General Questions About
4K PTZ Pro Lens
This camera is designed for online teaching, live streaming, video conferencing, and classroom recording with 4K resolution, 12X zoom features.
Yes, it supports RTMP and RTSP streaming, making it compatible with YouTube, Facebook Live, and other platforms.
Absolutely! It’s perfect for online teaching, hybrid learning, and business meetings, supporting Zoom, Google Meet, and Microsoft Teams.
Video & Image Quality
The camera supports 4K Ultra HD and multiple resolutions, including 1080p and 720p for different streaming needs.
Yes, it features auto-focus and advanced low-light performance, ensuring clear video even in dim lighting.
Connectivity & Compatibility
It supports HDMI, SDI, USB 3.0, USB 2.0, and IP streaming (RTSP/RTMP), making it versatile for various setups.
Yes, it supports remote control via RS232, RS485, and IP (VISCA over IP), allowing easy operation from a distance.
Installation & Setup
Yes, it supports PoE (IEEE802.3af), allowing power and data transmission through a single cable.
Yes, it works seamlessly with OBS, vMix, Zoom, Microsoft Teams, Google Meet, and other streaming software.
The camera can be wall-mounted, ceiling-mounted, or placed on a tripod for flexible installation.
Advanced Features
It supports a 170° pan, -30° to +90° tilt, and 12X optical zoom, providing a wide coverage area.
Pricing & Warranty
Prices may vary. Please check the official product page for the latest price.
The AIWaft 4K PTZ Pro Lens Camera has a 3-year manufacturer’s warranty for peace of mind.
